Universal Heat Flux Sensors, F
Order-No: C01-100-xxx Series/Model:
Universal Heat Flux Sensors for Industry, Laboratory and Research
Main Product Features
- Direct Heat Flux Readout
- Measures Bidirectional Heat Flow
- Sensitivity unaffected by Vacuum
- Self-generating Output - requires no Amplifier no Power Supply or Reference Junction
- Easy to install - stick (glue) on or screw on
The wafer thin heat flow sensor is sensitive to heat passieg through it. Consequently, it responds to all three modes of heat fluxes: heat conduction, heat radiation and heat convection, or in combinations. The majority of it\'s uses consists of recording heat energy entering or leaving a surface of a wall or body.
Each side of the sensor has the same nominal sensitivity. i.e., it is bidirectional. It\'s self-generating millivolt output, which is proportional to heat flow, can be used to measure and/or control. The models with integral thermocouple are designed to measure both heat flux and temperature.
Each side of the sensor has the same nominal sensitivity. i.e., it is bidirectional. It\'s self-generating millivolt output, which is proportional to heat flow, can be used to measure and/or control. The models with integral thermocouple are designed to measure both heat flux and temperature.
Applications:
- Green Roof and Soil
- Insulation Evaluation of Roofs, Walls ect.
- Submarines and Vessels
- Biomedical
- Pipes and Ducts
- Refineries and Reactors
- Aero-Space
